Slim Profile surface mounted and suspended luminaires have become more common for the general illumination of offices, schools, health care facilities and public buildings. The difference is performance and comfortable is striking. While many ‘Panel lights’ look the same, most are unable to provide the low glare, uniformity needed to meet Australian standards. furthermore, the light output drops dramatically in cheaper brands very quickly, rendering the product useless and needing to be changed. A saving may have been met initially by using poorly designed, cheaper troffers, the ultimate cost is great – this is explained in our webinar ‘Economics of lighting’. With the U2/R2 series, ETAP teams these intrinsic advantages with superior performance, minimalist look and long service life.
The R2 is offered in linear or square shapes for surface mounting or suspended installations. Like all of ETAP’s surface/suspended products, the option for continuous or in-line installation is available. The R2 is offered is a recessed version called the U2 with options of U23 being similar to the R2, or the U25 with Meso optics – a High performance product.
Brightly and evenly illuminated spaces – U2/R2 recessed luminaires guarantee brightly and evenly illuminated spaces in which it is pleasant to work or stay. They are also finished to a high standard. R2 luminaires also create uniform light comfortable lighting across interior spaces including appearances of lighting on the ceiling with the diffuser’s homogeneous illumination. The U2 – R2 is up to 143Lm/W
High efficiency – R2 luminaires provide well designed light distribution with particularly high efficiency. This will allow you to keep energy consumption under control and illuminate your spaces with the fewest possible luminaires – even where stringent requirements are imposed in terms of lighting level and comfort. The U2 – R2 will help reach our BCA requirements for green-star building.
Smart investment – The LEDs’ long service life and high lumen maintenance turn the U2 series into a smart investment for the long term. With the smooth cover plate luminaires are easy to clean. They form a compact, sealed unit, thus keeping dirt and insects at bay, with these attributes The U2 – R2 is a perfect product for Hospital, commercial Kitchens and other Clean room environments. The U2 is designed in such a way that LEDs and driver can be effortlessly replaced after at the end of the operational life of the LED or driver. LLMF=98%@50Khrs
Add K9 Emergency, light sensors or motion sensors inbuilt into the U2 – R2 for less visible services on the ceiling.
Specification:
Size:
Square – 598mm x 598mm
Linear – 1198 x 298 x 50mm
Power: 3400 – 4200Lm
LLMF = 90%@50khrs
UGR from <19
Luminous Efficiency up to 143Lm/W
Please contact Bluelab for support.
For ETAP's full R2 range click here
